Ex 11.1 Q4 - A chord of a circle of radius 10 cm subtends a right angle at the centre. Find the area of the corresponding : (i) minor segment (ii) major sector. (Use π = 3.14)
Solution:-Given,
Radius = r = 10 cm
Angle = 𝜃 = 90°
Let,
AB be the chord which subtends a right angle at centre 'O' of the circle.
Quick Recap:
Minor segment: The smaller region of the circle formed by a chord and the arc it intercepts.
Major sector: The larger region enclosed by two radii and the arc between them.
( i ) Area of Minor Segment:
*Area of Minor Sector OACB
=
𝜃
/
360°
× πr² =
90°
/
360°
× 3.14 × (10)² =
1
/
4
× 3.14 × 100 =
314
/
4
= 78.5 cm²
*Area of ∆AOB
=
1
/
2
× Base × Height =
1
/
2
× OA × OB =
1
/
2
× 10 × 10 =
100
/
2
= 50 cm²
∴ Area of Minor Segment ACB
= Area of Minor - Area of ∆AOB
Sector OACB
= 78.5 - 50
= 28.5 cm²
Therefore, Area of Minor Segment is 28.5 cm².
( ii ) Area of Major Sector:
*Area of Major Sector OADB
=
360° - 𝜃
/
360°
× πr² =
360° - 90°
/
360°
× 3.14 × (10)² =
270°
/
360°
× 3.14 × 100 =
3
/
4
× 314 =
942
/
4
= 235.5 cm²
Alternatively..
*Area of Major Sector OADB
= πr² - Area of Minor Sector OACB
= 3.14 × (10)² - 78.5
= 3.14 × 100 - 78.5
= 314 - 78.5
= 235.5 cm²
Therefore, Area of Major Sector is 235.5 cm².
Hence,
The area of Minor Segment and Major Sector is 28.5 cm² and 235.5 cm² respectively.
------------------------------------
Try This..
✒ A circular pizza has a radius of 12 cm. If a slice makes a 120° angle at the centre, find the area of the slice.
✒ A wheel makes 500 revolutions in moving 1.1 km. Find the radius of the wheel.
✒ A chord of a circle of radius 14 cm subtends an angle of 60° at the centre. Find the area of the corresponding minor segment.
✒ The minute hand of a clock is 10 cm long. Find the area swept by the minute hand in 30 minutes.
❌ Common Mistakes
Using the wrong formula:▸ Many students confuse sector and segment formulas. Always subtract the triangle’s area for a segment!Incorrect angle conversion:▸ Ensure you’re using degrees (not radians) unless specified.Skipping steps:▸ Missing out on calculating triangle area will lead to the wrong answer for the segment.Not using the given π value:▸ Always use π = 3.14 if it's mentioned in the question.
