Ex 9.1 Q6 - A 1.5 m tall boy is standing at some distance from a 30 m tall building. The angle of elevation from his eyes to the top of the building increases from 30° to 60° as he walks towards the building. Find the distance he walked towards the building.
Solution:- *PQ be the height of the boy
*AB be the height of the building
Given,
*Height of the boy = PQ = CB = 1.5 m
*Height of the building = AB = 30 m
∴ AC = AB - CB
∴ AC = 30 - 1.5
∴ AC = 28.5 m ------- (i)
*Angle of elevation from starting point Q to the top of the building = ∠APC = 30°
*Angle of elevation from final point S to the top of the building = ∠ARC = 60°
➙ In ∆APC, ∠ACP = 90°,
∴ tanP =
Opposite side of ∠P
/
Adjacent side of ∠P
∴ tan30° =
AC
/
PC
∴ tan30° =
28.5
/
PC
{ from (i) } ∴
1
/
√3
=
28.5
/
PC
{ ∵ tan30° = 1/√3 } ∴ PC = 28.5√3 ------- (ii)
➙ In ∆ARC, ∠ACR = 90°,
∴ tanR =
Opposite side of ∠R
/
Adjacent side of ∠R
∴ tan60° =
AC
/
RC
∴ tan60° =
28.5
/
RC
{ from (i) } ∴ √3 =
28.5
/
RC
{ ∵ tan60° = √3 } ∴ RC =
28.5
/
√3
*Multiplying Numerator and Denominator by √3,
∴ RC =
28.5
/
√3
×
√3
/
√3
∴ RC =
28.5√3
/
3
∴ RC = 9.5√3 ------- (iii)
Now,
*The distance walked by the boy towards the building
= QS
= PR
= PC - RC
= 28.5√3 - 9.5√3 { from (i), (ii) }
= 19√3
Hence,
The distance walked by the boy towards the building is 19√3 m.
------------------------------------
Try This..
✒ A kite is flying at a height of 60 m. The angle of elevation is 30°. Find the length of the string.
✒ The angle of elevation to the top of a building from two points on the ground is 30° and 60°. Find the distance between the two points.
✒ A man standing 40 m away from a tower sees the top of the tower at 45°. Find the height of the tower.
❌ Common Mistakes
▸ Forgetting to subtract the height of the observer (like the 1.5 m of the boy here).▸ Using wrong trigonometric values (like confusing tan 30° and tan 60°).Skipping diagrams:▸ A rough sketch can save you from silly errors.
